2000–4000 kVA Dry Type Transformers in Bangladesh | Edison Power

In powering large-scale infrastructure and utility networks, ensuring performance and safety cannot be compromised.
2000–4000 kVA dry type transformers, assembled by Edison Power, deliver high-efficiency, low-maintenance, and fire-safe power solutions for power plants, industrial substations, and mega infrastructure projects across Bangladesh.

These high-capacity transformers are engineered perfectly providing advanced insulation systems, superior cooling, and minimal loss cores, which leads to continuous operation under demanding load conditions. Every model of Edison Power is ISO 9001 and IEC 60076 compliant, guarantees safety, durability, and consistent energy delivery for years.

Overview

2000–4000 kVA Dry Type Transformers in Bangladesh

Designed for Critical Power Applications

Edison Power’s mega-range dry type transformers are built to handle industrial-scale power distribution, operating safely without oil or liquid insulation.

Key design goals:

  • High-capacity reliability: for long operating hours.
  • Fire-safe construction: with Class H insulation systems.
  • Moisture and dust resistance: ideal for Bangladesh’s tropical climate.
  • Low electromagnetic noise: for sensitive environments.
  • Eco-friendly materials — zero oil, zero contamination.

These models are mostly reliable for power generation plants, EPC contractors, export processing zones, and infrastructure developers that need consistent voltage regulation & uninterrupted power distribution and compliance with BPDB & DOE standards.

Technical Specifications (2000–4000 kVA Range)

Model (kVA)
 Dimension (mm)
 No-Load Loss (W)
 Full-Load Loss (W)
 Impedance (%)
2000 kVA L-1450 × W-1050 × H-1600
 1850 18900 6%
2500 kVA L-1500 × W-1100 × H-1620
 2000 21700 6%
3000 kVA L-1580 × W-1270 × H-1660
 2170 25300 6%
3150 kVA L-1700 × W-1350 × H-1750
 2300 27800 6%
4000 kVA
 L-1960 × W-1400 × H-1800
 3500 31950 6%

These transformers ensure compliance and safety even in high-fault environments because each transformer faces type, routine, and special tests—including surge voltage and thermal short-circuit testing.

Performance You Can Rely On

Dry type transformers from Edison Power outperform traditional oil-filled transformers in safety, durability, and installation flexibility.

Core Performance Benefits:

  • Continuous 24/7 operation for essential facilities.
  • Up to 98% efficiency under rated load.
  • Reduced total ownership cost due to low maintenance.
  • Natural or forced air cooling (AN/AF) for heat stability.
  • Minimal power loss through vacuum impregnated (VPI) windings.

These transformers ensure consistent voltage output even during peak loads or grid disturbances as they are capable of supplying large-scale machinery, grids, or substations.

Where Mega-Range Transformers Excel

This transformer range is designed for Bangladesh’s industrial and infrastructural backbone, offering dependable service for projects with massive energy demands.

Common Applications:

  • Power generation and distribution stations
  • Mega factories and export-oriented zones
  • Commercial and residential towers
  • Government utilities and power authorities
  • Industrial zones like airports, railway stations etc.

Each transformer is customizable according to their need (step-up or step-down voltage), and provide flexible enclosure options for indoor or outdoor installation.

Quality That Meets Global Standards

Edison Power integrates European-standard cores, copper windings, and precision-built insulation systems in every large transformer unit.

All production follows:

  • IEC 60076 / ANSI C57.12 guidelines
  • ISO 9001:2015 quality assurance
  • Complete FAT (Factory Acceptance Test) documentation
  • On-site installation and commissioning support

This ensures your transformer is not only efficient but audit-ready for industrial certification and EPC project compliance.

AMC & Maintenance for Large Transformers

Edison Power offers end-to-end maintenance and AMC support for high-capacity transformers, ensuring stable long-term performance.

Our AMC covers:

  • Thermal scanning and infrared load monitoring
  • Cooling and winding inspections
  • Insulation and tap changer testing
  • Emergency field servicing and fault recovery

Regular maintenance eventually increases transformer life and prevents downtime in critical facilities like substations and power plants.

Why Choose Edison Power

Edison Power has been a leading industrial and substation transformer company in Bangladesh for years because they ensure technical expertise, reliability, and service excellence.

Why Clients Trust Us:

  • 15+ years of proven industrial experience
  • Locally supported with nationwide service coverage
  • UK-standard design, assembled to global safety codes
  • BPDB & IEC-compliant testing procedures
  • Custom-built transformers tailored for each project

From factory installation to utility-scale substation design, Edison Power provides turnkey power solutions backed by reliable engineering support.

Explore More Ranges

Looking for smaller or intermediate capacity units?


Call to Action

Power the Future with Edison Power’s Mega-Range Transformers

Edison Power’s 2000–4000 kVA dry type transformers offer unmatched efficiency, safety, and reliability for the largest industrial and infrastructure projects in Bangladesh.


Hotline: +880 1755 626006 | ✉ power_info@edison-bd.com
 Request a quote or technical consultation today.
