1000–1600 kVA Dry Type Transformers in Bangladesh | Edison Power

For heavy industries and high-load facilities, uninterrupted and safe power delivery is non-negotiable.Edison Power’s 1000–1600 kVA dry type transformers are built for nonstop industrial operations by maintaining stable voltage control with minimized energy loss.

These transformers are manufactured under ISO 9001 and IEC 60076 standards & combine high efficiency, superior insulation, and fire-safe construction. This makes them ideal for manufacturing plants, large offices, EPC projects, and power distribution substations in Bangladesh.

Overview

1000–1600 kVA Dry Type Transformers in Bangladesh

Industrial-Grade Performance You Can Trust

Dry type transformers are the preferred choice for modern industrial projects that demand performance without compromising safety.
Edison Power’s (from 1000 kVA –1600 kVA) range offers:

Flame-retardant construction — safe for inside use and enclosed environments.
High thermal endurance — Class F/H insulation withstands extreme heat.
Efficient cooling systems — Natural (AN) or Forced Air (AF) for 24/7 operation.
Robust short-circuit strength — engineered for motor-heavy and fluctuating loads.
Zero oil leakage — ideal for pollution-controlled zones and confined spaces.

These transformers are reliable for textile industries, manufacturing plants, educational institutions, and industrial estates of Bangladesh.

Technical Specifications (1000–1600 kVA Range)

Model (kVA)	Dimension (mm)	No-Load Loss (W)	Full-Load Loss (W)	Impedance (%)
1000kVA	L-1100 × W-865 × H-1415	1170	10100	5.5%
1250kVA	L-1270 × W-895 × H-1520	1250	12600	5.5%
1600kVA	L-1330 × W-995 × H-1570	1500	14300	6%

Each transformer is inspected for load endurance, insulation resistance, and magnetic flux control, which ensures long-term reliability even in demanding factory conditions.

The 1000 kVA model is mostly popular for industrial setups due to its size-to-performance ratio, while the 1600 kVA model is ideal for EPC and power distribution systems.

Built for Bangladesh’s Industrial Conditions

Bangladesh’s rapid industrialization means increased demand for durable, maintenance-free, and energy-efficient transformers. Edison Power’s dry type units are designed for exactly that.

Key Design Benefits

Operates without any kind of interruption in high humidity and dust-prone environments
Provides stable voltage output even during major fluctuations.
Compact footprint suitable for indoor or rooftop substations.
Lower operational noise — under 65 dB @ 7 meters.
Decreased full-load losses eventually improve plant-wide energy savings.

Every model is made of copper windings and technology to enhance insulation and extend transformer life.

Applications of 1000–1600 kVA Dry Type Transformers

This capacity range is ideal for industrial and large commercial infrastructures that depend on consistent voltage and long operating hours.

Common Use Cases

Textile and apparel manufacturing units.
Cement and steel plants.
Large universities, data centers, and hospitals.
Substations in EPC or hybrid energy systems.
Export-focused industrial areas.

Edison Power’s transformer ensures reliable power supply across industrial estates in Gazipur, Narayanganj, Chattogram, and Dhaka EPZ by maintaining voltage stability.

Efficiency, Safety, and Compliance

Each model is tested according to IEC 60076, ensuring:

Thermal stability under peak load conditions.
Electrical endurance against transient voltages.
Mechanical rigidity for vibration resistance.
Noise and heat reduction to meet Bangladesh DoE standards.

These transformers help industries meet local and global energy compliance while minimizing downtime and power loss.

AMC & After-Sales Support

Edison Power provides full AMC (Annual Maintenance Contract) and after-sales service for dry type transformers.

Our maintenance programs include:

On-site inspection & thermal imaging
Cooling and insulation testing
Tap changer and terminal check-ups
Preventive maintenance scheduling

Each AMC is handled by certified technicians to ensure maximum transformer uptime and reliability.

Why Choose Edison Power for Industrial Transformers

Edison Power has been at the top of industrial power distribution solutions in Bangladesh for more than a decade.

Our Strengths:

UK-assembled components and verified copper windings
Engineering expertise for industrial and EPC installations
ISO 9001 & IEC-certified production
Local support with 24/7 service teams
Custom design & consultation for project-specific requirements

We assist industrial clients build safer, smarter, and more efficient power systems by our 24/7 after-sales service.
