100–400 kVA Dry Type Transformer in Bangladesh

Power reliability starts with the right transformer — and at Edison Power, we design 100–400 kVA dry type transformers that are built to perform in Bangladesh’s challenging industrial conditions.

This small-capacity range is preferable for factories, office buildings, educational institutions, and commercial complexes which requires steady voltage control without the maintenance challenges of oil-filled units.

Each transformer is manufactured in ISO 9001-certified facilities and tested to meet IEC and ANSI standards which ensures safety, energy efficiency, and performance. With zero risk of oil leakage and enhanced fire resistance, our dry type models are the preferred choice for indoor installations and compact substations.

Overview

100–400 kVA Dry Type Transformers in Bangladesh

Engineered for Safety and Performance

100 kVADry type transformers are being popular in Bangladesh day by day for their consistent output they deliver while eliminating the risks associated with traditional oil-filled systems.

At Edison Power, every unit (100 kVA - 400 kVA) are built with:

Copper windings for optimal conductivity and durability.
Class F or H insulation systems, providing superior thermal endurance.
Natural Air Cooling (AN) or Forced Air Cooling (AF) options ensure high-efficiency heat dissipation.
Low-loss magnetic core materials minimize energy waste.
Precision-wound coils decrease mechanical stress and vibration.

Our transformers are ideal for urban, industrial, and institutional setups making them both silent and efficient.

Technical Specifications (100–400 kVA Range)

Model (kVA)	Dimension (mm)	No-Load Loss (W)	Full-Load Loss (W)	Impedance (%)
100kVA	L-920 × W-840 × H-1340	240	1650	4%
150kVA	L-1100 × W-865 × H-1415	290	2400	4%
200kVA	L-1270 × W-895 × H-1520	400	2800	4%
250kVA	L-1330 × W-995 × H-1570	490	3300	4%
315kVA	L-1450 × W-1050 × H-1600	570	3760	4%
400kVA	L-1500 × W-1100 × H-1620	610	4850	4%

All models are now available in both step-up and step-down configurations. The compact design, reduced noise output, and high impedance control make this range ideal for low to medium voltage distribution systems.

Key Benefits of Edison Power Dry Type Transformers

1. Safe and Eco-Friendly

Without any use of oil or toxic coolant, these transformers are fire-safe and environmentally sustainable and perfect for hospitals, schools, and enclosed facilities.

2. Energy-Efficient Performance

For its precision-engineered magnetic cores and optimized coil designs, each unit operates with minimal energy loss.

3. Easy Installation & Low Maintenance

No oil testing, refilling, or leakage inspection required — saves time and cost for facility owners.

4. Compact and Noise-Free Operation

Their low noise levels make them ideal for commercial and high-rise installations, where silent operation is a must.

5. Built for Bangladesh Conditions

High humidity, fluctuating voltage, or dust? Our dry type transformers are playing their best role against environmental stress by ensuring consistent performance in all the climates of Bangladesh.

Common Applications

Edison Power’s 100–400 kVA range is widely used across diverse industries:

Small and medium factories require steady voltage and clean power.
Office buildings and commercial complexes needing silent indoor transformers.
Educational institutions and medical facilities require fireproof solutions.
Renewable energy setups as step-up or step-down components in solar and hybrid power systems.

Every model provides maximum reliability with minimum maintenance, which helps clients avoid costly downtime and electrical risks.

Installation & AMC Support

Edison Power’s support doesn’t end with delivery. We provide complete installation, testing, and Annual Maintenance Contracts (AMC) across Bangladesh.

Our service includes:

On-site commissioning and insulation verification
Periodic inspection and thermal imaging
Load testing and cooling system assessment
Emergency service response and spare parts availability

Every AMC package is handled by trained professionals, ensuring that your power systems operate at peak performance.

Why Industrial Buyers Trust Edison Power

With over a decade of experience, Edison Power has become a preferred partner for EPC contractors, manufacturing plants, and infrastructure developers across Bangladesh.

Our reputation is built on-

Genuine product sourcing
Fast technical support
Compliance with BPDB and IEC regulations
Proven track record in industrial installations nationwide

We don’t just sell transformers — we deliver long-term reliability and continuous operational assurance for every client.

Explore More Ranges

Looking for higher capacities?

➡ 500–800 kVA Dry Type Transformers

or go back to the main category:

➡ Dry Type Transformer in Bangladesh

Power Your Business with Edison Power’s Small Range Transformers

Choose a 100–400 kVA dry type transformer which is built for performance ensuring safety and energy efficiency. Don’t forget to contact our technical team today for a free consultation, custom design, or quotation.

Hotline: +880 1755 626006 | ✉ power_info@edison-bd.com
