1000 kVA Dry Type Transformer in Bangladesh | Edison Power
Edison Power’s 1000 kVA dry type transformer is built for demanding industrial and institutional operations across Bangladesh.
Ensuring UK-standard design and IEC-certified safety, Edison Power delivers high efficiency, reduced power loss, exceptional reliability, consistent voltage stability and is used in factories, universities, and substations etc.
Edison Power ensures ISO 9001 and IEC 60076 standards for mechanical strength, thermal stability, and electrical endurance. Now they are one of the most reliable transformer manufacturers of Bangladesh.
Overview
1000 kVA Dry Type Transformer in Bangladesh
Key Features & Performance Highlights
Edison Power ensures capacity, safety, and long-term durability. Their transformers are manufactured to run continuously under heavy industrial loads.
Main Features:
- Rated capacity: 1000 kVA, 3-phase, 50 Hz
- Cooling method: AN/AF (natural or forced air)
- Insulation class: F or H (VPI-treated windings)
- Efficiency: >98% under full load
- Noise level: ≤65 dB @ 7m
- Mounting: Indoor or outdoor enclosure (custom)
Advantages
- Oil-free construction — prevents fire hazards and leakage issues.
- Compact size — fits tight electrical rooms or basement substations.
- Reduced maintenance — no oil testing, topping-up, or replacement.
- High thermal endurance — resists Bangladesh’s heat and humidity.
- Eco-safe operation — low noise, no emissions, 100% recyclable materials.
Technical Specifications
| Model |
Power (kVA) |
Dimension (mm) |
Dimension (mm) |
Full-Load Loss (W) |
Impedance (%) |
| WP1000 | 1000 | L-1100 × W-865 × H-1415 |
1170 | 10100 | 5.5% |
Built for medium to large power systems which ensures stable voltage regulation under variable loads. Its copper windings and low-loss silicon steel core minimize energy waste while extending operational life of the transformer.
Typical Applications
The 1000 kVA dry type transformer is designed for facilities that demand continuous power, low downtime, and safety compliance.
Used in
- Factories & industrial plants — supports heavy machinery and production lines.
- Universities & hospitals — reliable, fire-safe indoor operation.
- Commercial complexes & data centers — stable power for sensitive systems.
- Substations — step-down voltage for industrial distribution.step-down voltage for industrial distribution.
This model is a preferred choice for EPC contractors and institutional projects needing clean power with minimal risk.
Why Choose Edison Power
Edison Power has become a leading name in industrial and institutional power solutions across Bangladesh.
Our Commitment
- Over 15 years of transformer engineering experience.
- UK-assembled transformer components and BPDB-standard quality assurance.
- Strictly compliant with IEC, ISO, and ANSI standards.
- Factory and on-site testing before every delivery.
- Full technical documentation and after-sales service.
You’re investing in long-term reliability, lower total operating cost, 24/7 technical support by choosing Edison Power.
AMC & Maintenance Support
To ensure uninterrupted operation, Edison Power offers Annual Maintenance Contracts (AMC) and technical servicing for all transformer units.
Our maintenance includes:
- Regular insulation and load checks
- Cooling and winding performance verification
- Thermal imaging and fault detection
- Emergency repair and spare parts replacement
Each AMC program is designed to extend equipment lifespan and prevent costly downtime. Learn More: Transformer AMC & Maintenance Service.
Related Models
Looking for similar capacity transformers?
- 1250 kVA Dry Type Transformer
- 1600 kVA Dry Type Transformer
- Back to Dry Type Transformer in Bangladesh
Upgrade to Edison Power’s 1000 kVA Dry Type Transformer Edison Power provides power reliability, safety, and efficiency for your industrial or institutional project. Contact our team for consultation or a customized quotation today.
